| Form Factor | 4U Rackmount
Enclosure: (17.6" x 7" x 34.1")
Package: (31.89" x 29.92" x 44.88") |
| Processor | Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors
Up to 36C/72T; Up to 54MB Cache per CPU |
| System Memory | Slot Count: 16 DIMM slots
Max Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMM |
| Drive Bays | Default: Total 66 bays
2 rear hot-swap 2.5" SATA drive bays
4 rear hot-swap 2.5" NVMe* drive bays
60 top-loading hot-swap 3.5"/2.5" SAS/SATA drive bays
(*NVMe support may require additional storage controller and/or cables)
M.2: 2 M.2 NVMe slots (M-key) |
| Expansion Slots | Default: 3 PCIe 4.0 x16 LP slots |
| On-Board Devices | Chipset: Intel® C621A
Network Connectivity: 2 RJ45 10GBASE-T |
| Input / Output | LAN: 1 RJ45 1 GbE Dedicated BMC LAN port
2 RJ45 10 GBASE-T LAN ports
USB: 2 USB 3.0 ports (rear)
Video: 1 VGA port
DOM: 2 Super DOM (Disk on Module) ports |
| System Cooling | Fans: 6 Heavy Duty 8cm Fan(s)
Air Shroud: 1 Air Shroud |
| Power Supply | 2x 2000W Redundant Titanium Level (96%) Hot-plug power supplies |
| System BIOS | BIOS Type: AMI 128MB SPI Flash EEPROM |
| Management | SuperCloud Composer®
Supermicro Server Manager (SSM)
Supermicro Update Manager (SUM)
Supermicro SuperDoctor® 5 (SD5)
Super Diagnostics Offline (SDO)
Supermicro Thin-Agent Service (TAS)
SuperServer Automation Assistant (SAA) |
| PC Health Monitoring | CPU: Monitors for CPU Cores, Chipset Voltages, Memory 4+1 Phase-switching voltage regulator
FAN: Fans with tachometer monitoring, Status monitor for speed control, Pulse Width Modulated (PWM) fan connectors
Temperature: Monitoring for CPU and chassis environment, Thermal Control for fan connectors |
|
