| Form Factor | 2U Rackmount
Enclosure: 438.4 x 89.8 x 789.9mm (17.2" x 3.5" x 30.8")
Package: 673.1 x 254 x 1098.55mm (26.5" x 10" x 43.25") |
| Processor | Dual Socket E (LGA-4677) 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors |
| System Memory | Slot Count: 32 DIMM slots
Max Memory (2DPC): Up to 8TB 5600MT/s ECC DDR5 RDIMM/LRDIMM |
| Drive Bays | Default: Total 24 bays
24 front hot-swap E3.S 1T NVMe drive bays
M.2: 2 M.2 NVMe/SATA slots (M-key 2280/22110) |
| Expansion Slots | Default: 4 PCIe 5.0 x8 FHHL slots
2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)
Option A: 2 PCIe 5.0 x8 FHHL slots
1 PCIe 5.0 x16 FHHL slot
2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)
Option B: 2 PCIe 5.0 x16 FHHL slots
2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible) |
| On-Board Devices | Chipset: Intel® C741
Network Connectivity: Via AIOM |
| System Cooling | Fans: 4 Heavy Duty 8cm Fan(s)
Air Shroud: 2 Air Shrouds |
| Power Supply | 1x 2000W Redundant Titanium Level (96%) power supply |
| Management | SuperCloud Composer®
Supermicro Server Manager (SSM)
Supermicro Update Manager (SUM)
Supermicro SuperDoctor® 5 (SD5)
Super Diagnostics Offline (SDO)
Supermicro Thin-Agent Service (TAS)
SuperServer Automation Assistant (SAA) |
| PC Health Monitoring | CPU: Monitors for CPU Cores, Chipset Voltages, Memory 7 Phase-switching voltage regulator
FAN: Fans with tachometer monitoring, Status monitor for speed control, Pulse Width Modulated (PWM) fan connectors
Temperature: Monitoring for CPU and chassis environment, Thermal Control for fan connectors |
| Dimensions and Weight | Weight: Gross Weight: 77 lbs (34.93 kg)
Net Weight: 55 lbs (24.95 kg)
Available Color: Silver |
