SYS-E100-13AD-G1

Pre-built and ready to deploy.

  • CPU: Single Intel® Core™ i3-1215UE (6C)
  • Memory: 16GB DDR5-4800
  • Storage: 1x 256GB M.2 SATA SSD
  • Networking: Onboard dual 2.5GbE RJ45
  • Power Supply: Single 84W



Key FeaturesWi-Fi enabled system. Optional Intel® Wi-Fi 6E AX210 Gig+ integration with support for Wi-Fi 4, 5, 6, 6E R2, and Bluetooth® 5.3
Alder Lake-U 12th Generation Intel® Core™ i3-1215UE
2x DDR5-4800MT/s Non-ECC SO-DIMM max 64GB
M.2 M/B/E-Key with Nano SIM Card Slot
2x LAN 2.5GbE
Fanless (Op. Temperature 0C ~ +50C)
4 Independent Displays: HDMI2.0b/1.4b + DP 1.4a (Alt mode USB Typ-C)
Key ApplicationsIndustrial Automation
Retail
Smart Medical Expert Systems
Digital Signage Kiosk
Interactive info system
IoT Gateway for Smart Factory
Smart Building
Security and Surveillance







Form FactorFanless Embedded Enclosure: 195 x 44 x 150mm (7.68" x 1.73" x 5.94")
Package: 300 x 130 x 279mm (11.81" x 5.12" x 11")
ProcessorSingle FCBGA-1744 Intel® Core™ i3-1215UE
Up to 6C/12T
Up to 10MB Cache
System MemorySlot Count: 2 DIMM slots/2 Channels
Max Memory (2DPC): Up to 64GB 4800MT/s non-ECC DDR5 SO-DIMM
Drive Bays Configuration1 M.2 PCIe 4.0 x4 NVMe slot (M-key 2242/2280)
1 M.2 SATA slot (B-key 2242/2280; USB 3.0)
Expansion Slots1 M.2 SATA slot (B-key 2242/2280; USB 3.0)
1 M.2 slot (E-key 2230; USB 2.0)
1 M.2 PCIe 4.0 x4 NVMe slot (M-key 2242/2280)
On-Board DevicesChipset: Intel System on Chip
Network Connectivity: 2 RJ45 2.5GbE with Intel® I225-IT
Input / OutputLAN: 2 RJ45 2.5 GbE LAN ports (Intel® I225-IT)
USB: 2 USB 3.2 Gen1 Type-C ports (front), 2 USB 3.2 Gen1 Type-A ports (front), 4 USB 2.0 Type-A ports (rear)
Video: 1 HDMI 2.0b port (front), 1 HDMI 1.4b port (front), 2 Mini-DP 1.4 ports (front)
Serial: 4 COM ports (rear)
TPM: 1 TPM Onboard/port 80
System CoolingFans: N/A
Power Supply1x 84W power supply
System BIOSBIOS Type: AMIUEFI
BIOS Features: ACPI 6.4, SMBIOS 3.5 or later, UEFI 2.8, PCI F/W 3.0
ManagementSupermicro SuperDoctor® 5 (SD5)
Dimensions and WeightWeight: Gross Weight: 4.3 lbs (1.95 kg)
Net Weight: 2.16 lbs (0.98 kg)
Available Color: Black
Operating EnvironmentRoHS Compliant
Operating Temperature: 0°C to 50°C (32°F to 122°F)
Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
MotherboardSuper X13SAN-L-WOHS
ChassisCSE-E101-04
$838.00
